Smart GNSS Geodetic Antenna LCY3703A
Smart GNSS Geodetic Antenna LCY3703A
Smart GNSS Geodetic Antenna LCY3703A
Smart GNSS Geodetic Antenna LCY3703A
Smart GNSS Geodetic Antenna LCY3703A
Product Description
The LCY3703A is a high-performance smart GNSS geodetic antenna that excels in satellite signal tracking, supporting Beidou, GPS, and GLONASS signals. Designed for high precision and multi-constellation compatibility, it can be used with various receivers in diverse applications, including mobile mapping and precision agriculture.
Product Features
Smart GNSS Geodetic Antenna LCY3703A
Supports BD B1/B2/B3,GPS L1/L2,GLONASS L1/L2 signal reception
Stable phase center guarantees the accuracy of positioning within millimeter-level
Strong Anti-interference Performance
High gain, miniaturization, high sensitivity
IP67 ruggedized design can protect product from dust and water
Specifications
| Antenna | |
| Frequency Range（MHz） | BD B1/B2/B3 GPS L1/L2 GLONASS L1/L2 |
| Gain(dBi) | 4.5 |
| VSWR | ≤2.0 |
| Antenna AR （dB） | ≤3.0 |
| Phase Center Error（mm） | ±2 |
| Polarization | RHCP |
| Port Impedance（Ω） | 50Ω |
| LNA | |
| LNA Gain（dB） | 40±2 |
| Noise Figure | ≤2.0 |
| Operating Voltage（V） | 3-15 VDC |
| Operating Current（mA） | ≤45mA |
| Physical | |
| Connector Type | TNC-K |
| Antenna size（mm） | Φ100×36.5mm |
| Operating Temperature（℃） | -40-+70 ℃ |
| Storage Temperature（℃） | -55-+85 ℃ |
| Waterproof Grade | IP67 |
